XPZ200 × 75 double rollers crusher

Harmonized System:8474209000

The double roll crusher is smooth, applicable to the laboratory and laboratory coal and other medium and fine ores or low hardness of rock, the compressive strength 700kg /cm2 than. This machine is mainly by the base, with security spring rolls, components by motor through triangular pulley roller chain transmission, two, according to the opposite direction, extrusion materials. Roll gap can be within the prescribed scope to control adjusting feed size.

Roll size: Φ 200 × 75mm

The grain-size: acuities 13mm

The grain-size: < 3mm

Power:three-phase AC 380V ± 10%, frequency 50HZ

Power: about 1.5 KW

The weight : 200kg

Shape dimension (long×width×high) mm: 640×455×875
